0.5~1.5mm2(22-16) Imax=19A
ITEM.NO. US SYSTEM
OF BOLTS
d2 DIMENSION COLOR
B(mm) L(mm) F(mm) H(mm) D Ф(mm)
RV1.25-3 #4 3.2 5.7 17.8 4.95 10.0 4.3 Red
RVS1.25-3.5

#6

3.7 5.7 17.8 4.95
RVM1.25-3.5 #6 3.7 6.6 20.1 6.3
RVL1.25-3.5 #6 3.7 8.0 21.5 7.0
RVS1.25-4 #8 4.3 6.6 20.1 6.3
RVL1.25-4 #8 4.3 8.0 21.5 7.0
RV1.25-5 #10 5.3 8.0 21.5 7.0
RV1.25-6 1/4 6.5 11.6 27.5 11.1
RV1.25-8 5/16 8.4 11.6 27.5 11.1
RV1.25-10 3/8 10.5 13.6 31.6 13.9

1.5~2.5mm2(16-14) Imax=27A
ITEM.NO. US SYSTEM
OF BOLTS
d2 DIMENSION COLOR
B(mm) L(mm) F(mm) H(mm) D Ф(mm)
RV2-3 #4 3.2 6.6 17.8 4.3 10.0 4.9 blue
RVS2-3.5

#6

3.7 6.6 17.8 4.3
RVM2-3.5 #6 3.7 6.6 21.0 7.0
RVL2-3.5 #6 3.7 8.5 22.5 7.75
RVS2-4 #8 4.3 6.6 21.0 7.0
RVL2-4 #8 4.3 8.5 22.5 7.75
RVS2-5 #10 5.3 8.5 22.5 7.75
RVL2-5 #10 5.3 9.5 22.5 7.25
RV2-6 1/4 6.5 12.0 27.6 11.0
RV2-8 5/16 8.4 12.0 27.6 11.0
RV2-10 3/8 10.5 13.6 30.2 13.9

2.5~4mm2(14-12) Imax=37A
ITEM.NO. US SYSTEM
OF BOLTS
d2 DIMENSION COLOR
B(mm) L(mm) F(mm) H(mm) D Ф(mm)
RV3.5-4 #8 4.3 8.0 24.5 7.7 12.5 6.2 black
RVS3.5-5

#10

5.3 8.0 24.5 7.7
RVL3.5-5 #10 5.3 12.0 27.9 7.7
RV3.5-6 1/4 6.5 12.0 27.9 7.7

4~6mm2(12-10) Imax=48A
ITEM.NO. US SYSTEM
OF BOLTS
d2 DIMENSION COLOR
B(mm) L(mm) F(mm) H(mm) D Ф(mm)
RV5.5-3.5 #6 3.7 7.2 21.4 5.9 12.5 6.7 yellow
RVS5.5-4

#8

4.3 7.2 21.5 5.9
RVL5.5-4 #8 4.3 9.5 25.5 8.3
RV5.5-5 #10 5.3 9.5 25.5 8.3
RV5.5-6 1/4 6.5 12.0 31.5 13.0
RV5.5-8 5/16 8.4 15.0 33.7 13.7
RV5.5-10 3/8 10.5 15.0 33.7 13.7
RV5.5-12 1/2 13.0 19.2 38.1 16.0
