ITEM.NO. CLNLE SQ DIMENSION IMAX INSULATION COLOR
A.W.G mm2 I(mm) D Ф(mm) L(mm)
BV1.25 22~16 0.5~1.5 15.0 1.7 26.0 19A Red
BV2 16~14 1.5~2.5 15.0 2.3 26.0 27A blue
BV5.5 12~10 4~6 15.0 3.4 26.0 48A yellow
BV8 #8 6~10 21.0 4.5 32.0 62A red
BV14 #6 10~16 26.0 5.8 42.0 88A blue
BV22 #4 16~25 29.0 7.7 50.0 115A yellow
BV38 #2 35~50 32.0 9.4 55.0 160A red

ITEM.NO. CLNLE SQ DIMENSION IMAX INSULATION COLOR
A.W.G mm2 I(mm) D Ф(mm) L(mm)
PVT1.25 22~16 0.5~1.5 8.0 1.7 16.0 19A Red
PVT2 16~14 1.5~2.5 8.0 2.3 16.0 27A blue
PVT5.5 12~10 4~6 8.5 3.4 20.5 48A yellow
